ID86HZA3B1/C

Interactive Display

217 CM - 4K ULTRA HD (3840x2160)

IMMERSE LEARNING AT ANOTHER LEVEL

The next generation of digital technologies is transforming the way people live, work and study.
Whether we’re talking about a meeting in the office or a classroom, interactive displays meet the needs of
today’s customers in environments where communication and collaboration are necessary, enhancing  productivity and teamwork.

Multifunctional Solution

The interactive whiteboard offers a flexible solution  with cutting-edge features, including:
On-Touch Sharing (sharing and saving  annotations via QR code or email)
Wireless Screen Mirroring and Reverse  Mirror (PC / Mobile Phone / Tablet)
Ultra-thin aluminium frame design

Wireless Content Sharing

Easily wireless projection from your smartphone,  iPad, PC, or Mac. Content can be simultaneously  shared on up to 4 compatible displays.

Centralized Management

Streamline the management of interactive displays  through features such as:
Restart / Shutdown / Install applications
Factory reset
Screen Saver password setting
Intelligent sensor for temperature  measurement and control, with Pop-Up  notifications when the preset threshold is  exceeded.

Useful Tools

Various tools available to enhance the teaching /  presentation experience:
Ultra-fine 20px writing with a 2mm diameter on  the display, recognized with a precision of 1mm.
Image recording / freezing
Highlighting / Selection zoom.

Multiple Operating Systems*

You can enjoy increased flexibility / customization with  the optional OPS module,

which allows you to switch  between the pre-installed operating system (Android  13) and the Windows 10 SAC operating system of the  OPS module.

Simplified Communication

With the 48MP camera providing up to 4K video  resolution, along with the 8-zone omni-directional  microphone,

 you can experience clear communication  with high-quality audio and video.

*The images are for presentation purposes only. The design and specifications of the product may vary depending on the model and size. The product
and accessories may undergo modifications, but without affecting their functionalities. The floor mobile stand is not included in the package.

Technical Specifications

Display

 Diagonal: 86” (217cm)
 Resolution: 4K Ultra HD (3840 x 2160 px)
 Aspect Ratio: 16:9
 Backlight Technology: Direct LED
 Brightness: 450cd/m2 (with brightness sensor)
 Viewing Angle: 178⁰ (H) / 178⁰ (V)
 Contrast: 5000:1 (native)  / 100000:1 (dynamic)
 Response Time: 7ms
 Refresh Rate: 60 Hz
 Color Gamut Coverage: 72% NTSC, HDR10 Support

Touch

 Type:  Infrared (IR) Touchscreen with ZeroBonding technology   Touch Precision:  ±1mm (≥90%touch area)
 Touch Points:   45 multi-touch points
 Differentiated Recognition:  pen / object / palm / gestures
 Features:  Annotation over any source; Dual Tip / Color Pen
 Glass Screen Protection Layer:
o Toughened 3.2mm  /  Mineral Hardness 7 Mohs
o Anti- scratch /  Anti-glare

Hardware

 CPU Processor:
o Quad Core Cortex-A76  ( 4x 2.4GHz )
o Quad Core Cortex-A55  ( 4x 1.8GHz )   Dynamic Memory (RAM):    8 GB
 Internal Memory (ROM): 128 GB

Software

 Operating System (preinstalled, OTA updates):  Android 13     OPS-PC Module (optional): Windows 10 Enterprise SAC
 Multilingual Interface Support (36 languages, including:
Turkish, Hungarian, German, and Romanian)    Special Features:
o Integrated Whiteboard
o Content Sharing on Android, IOS, and Windows  platforms

Camera

 Image Resolution:  4K UHD (up to 48MP in photo-mode)
 Field of View: 120⁰ (diagonal), 110⁰ (horizontal), 75⁰ (vertical)
 Image Distorsion: ≤2.5%
 Camera Features: Intelligent switching between Android and  optional OPS module (Windows 10 Enterprise SAC)
 AI Features (Face & Voice) for speaker tracking:
o Speaker Auto-framing
o Speaker recognition / Face recognition

Speakers

 Output Power: 55W (2x15W + Subwoofer 25W)

Microphone

 Type:  Omni-directional with 8 zones   Special Features:
o Echo reduction
o Smart noise-cancellation   Voice Distance: 12 m
 Sampling Rate: 32 KHz
 Bit Depth: 16 bit

Connectivity

Input

 HDMI In:           x3  @ 4K 60Hz  (1x front / 2x rear)
 VGA:                  Yes
 Display Port:    Yes (v1.2)
 Audio In:           Yes
 USB (front):      x2 (v3.0)
 USB (rear):        x2 (v3.0) + x1 (v2.0)
 USB Type-C:     x2 (1x65W front / 1x15W rear)
 Touch-USB:      x3 (1x front / 2x rear)
 RJ45 (LAN):        x2  (1000 Mbps) with built-in network switch   RS232:               x1
 OPS-PC:            19V  80-pin slot

Output

 HDMI Out:         x1  @ 4K 60Hz   Audio Out:        Yes
 S/PDIF Out:       Yes
 WiFi Built-In:     Yes  /  WiFi 6  (802.11ax – 2.4Ghz & 5Ghz)
 Bluetooth:         Yes (version 5.1)  /  Bluetooth Low Energy (BLE)    Wireless Projection (NFC):   Yes  /  Screen Mirroring

Power Consumption

 Power Supply:  AC 100-240V 50/60Hz
 Maximum Power Consumption:  ≤ 350 W
 Standby Power Consumption:  ≤ 0.5W
 Life Time:  minimum 100.000 hours  (24/7 mode)

Dimensions

 Without Stand (WxDxH): 1960.5 x 82.5 x 1173.7 mm   Net Weight (without Stand): 84.6 Kg
 VESA Mount Standard:  800 x 400 mm, M8 25mm

Included Accessories

1x Power Cable (1.5m)
2x Passive Pens
1x HDMI 2.0 Cable (3.5m)
1x VESA Wall Mount bracket
1x User Manual
1x Warranty Certificate
1x Certificates: CE (LVD, RED, ErP, EMC), REACH, RoHS, WEEE
