Adata XPG PYMCORE 750W 80 PLUS GOLD

8 days

ID: 269518

Product Code: 75261729

107.64€

(Ex Tax: 88.96€)

Leasing

Delivery options

Description

Related products

The picture is for illustrative purposes only and the actual product may differ from the picture. Notice a mistake? Please let us know.

Description

PYMCORE SFX
UNDERSIZED. OVERPOWERED.
Introducing PYMCORE SFX PSU, the high power-density solution for your Small Form Factor PC. PYMCORE features High-Duty Capacitor Array, a ground-breaking topology of multiple premium Japanese capacitors that significantly improves power stability and delivers 128% higher power density within 56% smaller dimensions. 80 PLUS and Cybenetics GOLD certified plus ATX 3.1 compliant, this undersized PSU is going to overpower your SFF-Ready build!

Small Yet Powerful
PYMCORE SFX PSU comes in a compact size which is 56% smaller than the regular ATX PSU, while delivering 128% higher power density, making it perfect match for Small Form Factor PC with limited space.

Certified But Not Statisified
PYMCORE SFX PSU is certified as GOLD rating by 80 PLUS and Cybenetics. Moreover, it upholds the commitment by XPG to provide even higher efficiency than the GOLD standards.

High-Duty Capacitor Array
PYMCORE SFX PSU features High-Duty Capacitor Array, a ground-breaking topology consisted of multiple premium Japanese capacitors that significantly reduces ripple and optimizes circuit layout. As a result, it delivers 235% power excursion with top quality and reliability.

Cool And Quiet
With the FDB Fan, PYMCORE SFX PSU keeps the components cool while maintaining at low noise level and offers proven durability.

Futureproof: ATX 3.1 Compliant
PYMCORE SFX PSU is fully compliant with the ATX 3.1 guidelines and includes the latest 12V-2x6 (600W) PCIe cable for all the power-demanding components on your next-gen platforms.

Match For SFF-Ready
PYMCORE SFX PSU is the perfect match for the SFF-Ready compatible cases to empower your SFF-Ready enthusiast RTX 50 series graphics cards and unleash uncompromising performance.

Total power	750 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	10 A
Max output current (+3.3V)	20 A
Max output current (+12V)	62.4 A
Max output current (+5V)	20 A
Max output current (-12V)	0.4 A
Max output current (+5Vsb)	3 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection (SIP), Under voltage
Motherboard power connector	24-pin ATX
Peripheral (Molex) power connectors (4-pin)	2
Number of SATA power connectors	6
EPS power connector (8-pin)	Yes
PCI Express power connectors (6+2 pin)	2
PCI Express power connectors (12+4 pin)	1
Cabling type	Fully-Modular
Purpose	PC
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Gold
ATX version	3.1
Bearing technology	FDB
Mean time between failures (MTBF)	100000 h
Product colour	Black
Cooling type	Active
Fan diameter	9.2 cm
Number of fans	1 fan(s)
On/off switch	Yes
Width	100 mm
Depth	125 mm
Height	63.5 mm
Weight	1.84 kg
